产品特点
Single phase fan & blower motors are high quality and perfect performance. The electric motors can be customized according to your needs. Please contact us if you have any questions.
Series: | YUYM | Frame construction: | Rolled Steel |
Frame size: | 48Y | Enclosure : | ODP |
Power output: | 0.25 - 0.75HP | Insulation Class : | B |
Voltages: | 115V, | Cooling method: | IC411 |
Number of poles: | 4 | Certificates: | CCC, CE |
Ambient Temperature : | 40 °C | Mounting arrangements: | Resilient Base |
规格参数
| Type | HP | RPM | FRAME | VOLTAGE | FLA | OVER（LOAD） | S.F | INS.（CLASS） | ENCL. | DUTY | WGT（LB/KG） |
| YUYM484D1 | 0.25 | 1725 | 48Y | 115 | 3.9 | AUTO | 1.35 | B | ODP | CONT. | 13.8/6.3 |
| YUYM484D2 | 1 /3 | 1725 | 48Y | 115 | 4.4 | AUTO | 1 .35 | B | ODP | CONT. | 15.1/6.9 |
| YUYM484D3 | 1 /2 | 1725 | 48Y | 115 | 5.4 | AUTO | 1.25 | B | ODP | CONT. | 19.9 / 9 |
| YUYM484D4 | 0.75 | 1725 | 48Y | 115 | 8.4 | AUTO | 1 .25 | B | ODP | CONT. | 23.1 / 10.5 |
外形尺寸
产品应用
Single-phase fan motor has reliable operation and easy maintenance.Motors are suitable for belt-driven fans or fan applications on shafts.Electric motors can be customized according to your needs.If you have any questions, please contact us.
